Cube AMS Hybrid 177 C:62 TM 600X 2026

A bike built to take on the rowdiest mountain trails and come out on top needs components to match. So, for the AMS Hybrid 177 C:62 TM 600X, we began by selecting Fox's 38 Float Performance fork and matched it with a Float X2 Performance shock. Then we shod a pair of Newmen Beskar 30 wheels with Continental Argotal and Kryptotal 2.4in tyres, and added a set of Sram's powerful Maven Silver hydraulic disc brakes. There's a Kiox 400C controller to keep you on top of the Bosch CX drive and 600Wh battery's performance. And an ACID carbon crank pairs with Sram's Transmission 90 1x12 gears to get your power to the trail. It's ready. Are you?

We set out to make a lighter, more capable all-mountain e-mtb – and the AMS Hybrid 177 C:62 frame is the heart of it. Built from our C:62® carbon and featuring Bosch's BDU38YY motor mount for compatibility with both SX and CX motors, it features a built-in 600Wh PowerTube battery. We've tweaked the geometry and kinematics to suit a bike built to take on rowdy, technical trails at high speed. Mullet wheels and 170mm travel front and rear deliver epic handling, and an angle-adjustable headset means you can tweak the geometry to suit your own preference. Internal Cable Routing complements the frame's clean aesthetic and, of course, there's a UDH gear hanger and Direct Mount chain guard. Bring it on!

• Fork: Fox 38 Float Performance GRIP, Tapered, 15x110mm, 170mm
• Shock: Fox Float X2 Performance, 230x65mm, Adjustable HSC/LSC/LSR w/ 2-Pos. Lever
• Shock Hardware: Front: 30x8mm, Rear: w/o DU-Bushing 15 mm
• Headset: ACROS AZF-675, ICR (Integrated Cable Routing), Top Zero-Stack 1 1/2" (ZS 56mm), Bottom Zero-Stack 1 1/2" (ZS 56mm), Fiber Inserts for Angle Adjustment
• Stem: Newmen Evolution SL 318.4, 31.8mm
• Handlebar: Newmen Beskar 318.40 w/ VariGrip System
• Grips: Newmen Slat VGS
• Rear Derailleur: Sram Eagle 90 Transmission, 12-Speed
• Chain Guide: Reverse Flip-Guide E-Chain Guide, Direct Mount, I-Plate
• Shifters: Sram Eagle 90 Transmission
• Brake: Sram Maven Silver, Hydr. Disc Brake (200/200)
• Crankset: ACID MTB Hybrid Carbon, 36T
• Cassette: Sram XS-1275, 10-52T
• Chain: Sram GX Eagle™ Transmission
• Wheelset: Newmen Beskar 30 base/strong, 28/32 Spokes, 15x110mm/12x148mm, Tubeless Ready
• Front Tire: Conti Argotal, Enduro Super Soft, Tubeless Ready, 2.4
• Rear Tire: Conti Kryptotal Rear, Downhill Soft, Tubeless Ready, 2.4
• Pedals: ACID PP MTB
• Saddle: ACID Venec EMTB Trail 140
• Seat Post: CUBE Dropper Post, Handlebar Lever, Internal Cable Routing, 31.6mm
• Engine: Bosch Drive Unit Performance Line CX max. 100Nm (BDU38)
• Battery: Bosch PowerTube 600
• Charger: Bosch 4A
• Remote: Bosch Mini Remote
• Display: Bosch Kiox 400C
